FRAM CH11473 Part Description
Manufacturer
Product Description
FRAM, CH11473, Oil Filter
Features & Benefits
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- The perfect balance of dirt-trapping efficiency and dirt-holding capacity
- Includes gaskets and O-rings manufactured to endure the high pressures and high temperatures in today’s engines
Cartridge Oil Filter
FRAM CH11473 Specifications
Product Attributes
| Filter Media Material | Cellulose/Synthetic Blend |
| Height | 3.330 IN |
| Grade Type | Regular |
| Filter Type | Cartridge |
| Non Slip Grip | No |
| Anti-Drain Back Valve | No |
| Bypass Relief Valve | No |
| Grade | Advanced |
| Housing Color | NA |
| Inside Diameter Bottom | 1.228 IN |
| Meets Or Exceeds Original Equipment Manufacturer Specifications | Yes |
| New Or Remanufactured | New |
| O-ring (1) Inside Diameter | 0.622 IN |
| O-ring (1) Outside Diameter | 0.740 IN |
| O-ring (1) Thickness | 0.118 IN |
| O-ring (2) Inside Diameter | 0.393 IN |
| O-ring (2) Outside Diameter | 0.492 IN |
| O-ring (2) Thickness | 0.098 IN |
| O-ring Inside Diameter | 2.716 IN |
| O-ring Outside Diameter | 2.874 IN |
| O-ring Thickness | 0.157 IN |
| O-Rings Included | Yes |
| Outer Diameter Bottom | 2.570 in |
| Outer Diameter Top | 2.570 in |
| Replacable Filter | Yes |
| Reusable | No |
| Top Inside Diameter | 1.228 in |
| Torque Nut | No |
| Washable | No |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8421230000 |
| Warranty Special | See Rep |
| Warranty Special UOM | SR |
| Warranty Time | 30 |
| Warranty Time UOM | DA |
| UPC | 00009100559760 |
| UNSPSC | 15121501 |
FRAM CH11473 Part Interchanges
| Brand | Part Number |
|---|---|
| Champ | P1016 |
| Purolator | L18182 |
| Wix | WL7515 |
| LUBER-FINER | P1016 |
| Carquest | 94715, 95515 |
| Service Champ | C8182, WP1016 |
| Mann-Filter | HU711/6Z, HU 7044 Z |
| Hengst | E818HD236 |
| Warner | WP1016 |
| INFINITI | 15208-92C09, 15208-92C0N, 15208-HG00D |
| Mercedes-Benz | 270 180 0109, 270 184 0025, 270 184 0125, 2701800009, 2701800109, 2701840025, 2701840125, 2701840225, A270 180 0109 |
| Valvoline | VO-164 |
| MAHLE | OX 982D ECO |
| Nissan | 15208-92C09, 15208-92C0N, 15208-HG00D |
| Carquest Premium Filters | 95515 |
| Mighty Distributing System | MX9022 |
| Pennzoil | PZ-193 |
| Mahle | OX 982D ECO |
| STP Filters | S11473, S11473XL |
| ECOGARD | X10259 |
| Warner Filters | WP1016 |
| Motomaster OE Plus | MOCH11473 |
| FRAM Force | FF11473 |
| FRAM Titanium | FS11473 |
| FRAM Drive | FD11473 |
| MicroGard Select | MSL7515 |
FRAM CH11473 Fits Vehicles
- Freightliner Sprinter 1500 (2019-2020)
- Freightliner Sprinter 2500 (2019-2021)
- Suzuki Aerio (2002)
- Mercedes-Benz GLB35 AMG (2021-2024)
- Mercedes-Benz GLA35 AMG (2021-2024)
- INFINITI Q60 (2017-2018)
- Mercedes-Benz SLK300 (2016)
- Mercedes-Benz GLE350 (2020-2023)
- Mercedes-Benz Sprinter 1500 (2019-2023)
- Mercedes-Benz E350 (2020-2023)
- Mercedes-Benz Sprinter 2500 (2019-2023)
- Mercedes-Benz GLB250 (2020-2024)
- Mercedes-Benz A35 AMG (2020-2022)
- Mercedes-Benz CLA35 AMG (2020-2023)
- Mercedes-Benz A250 (2019-2022)
- Mercedes-Benz GLC300 (2016-2023)
- Mercedes-Benz A220 (2019-2022)
- Mercedes-Benz SLC300 (2017-2019)
- Mercedes-Benz GLC350e (2018-2020)
- INFINITI QX30 (2017-2019)
- Mercedes-Benz E300 (2017-2019)
- Mercedes-Benz C350e (2016-2018)
- Mercedes-Benz GLA250 (2015-2024)
- Mercedes-Benz C300 (2015-2023)
- Mercedes-Benz Metris (2016-2023)
- INFINITI Q50 (2016-2019)
- Mercedes-Benz CLA250 (2014-2024)
- Mercedes-Benz B250 (2013-2019)
