GROTE part description

Product Description

Opt

Features & Benefits

  • 22-18 (red) & 16-14 (blue) ring terminals are 10% thicker than standard terminals (8mm vs. 7mm)
  • 45˚ barrel provides visual inspection that the wire is stripped proper length & fully seated
  • All ring terminals comprised of copper with tin plating
  • Brazed seam barrel ensures superior crimp performance
  • Color-coded stripes identify wire gauge size to be used with connector and indicate/guide where to position crimp nest to install properly
  • Long Ring Terminal ensures a strong, waterproof seal
  • provides flush surface for maximum contact
  • & allows ring terminal to be stacked unimpeded by tubing
  • Serrations in crimp barrel provide strong mechanical termination

Product Attributes

Color Clear w/Yellow Stripe
Connection Type Ring Terminal
Functions Heat Shrinkable
Gauge 12-10 GA
Material Cross-linked ionic polymer
Operating temperature -55 degree C to 125 degree C (-67 degree F to 257 degree F)
Prop 65 Label Required N
Rohs Yes
Shrink Ratio Exceeds 2.5 to 1
Voltage 600V
Package Type Clamshell
Stud or Tab Size 3/8"

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8536900000
UPC 00621935023614
VMRS Code 053007002
