*Representative image - actual part not displayed
Centric 126.62166 - Centric Premium OE Style Slotted Brake Rotor
$64149
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium OE Style Slotted Brake Rotor
Features & Benefits
- Premium e-coated rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] Mm | 160.400 |
| OEM Vane Count [cntrc] | 48 |
| Hat Id [cntrc] In | 6.315 |
| Vane Style [cntrc] | Curved |
| Misc Holes [cntrc] | 1 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 12.820 |
| Weight [cntrc] Lbs | 28.250 |
| Discard Thickness | 32.000 MM |
| Discard Thickness | 1.260 IN |
| Nominal Thickness | 1.339 IN |
| Nominal Thickness | 34.000 MM |
| Hat Finish | Coated |
| Overall Height | 60.100 MM |
| Overall Height | 2.366 IN |
| Outside Diameter | 370.000 MM |
| Outside Diameter | 14.567 IN |
| ABS Tone Ring Included | No |
| Surface Type | Slotted |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 67.400 MM |
| Center Hole Diameter | 2.654 IN |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.500 MM |
| Stud/Lug Hole Diameter | 0.650 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590203998 |
Part Interchanges
Fits Vehicles
- Chevrolet Camaro (2017-2020)
- Cadillac ATS (2016-2019)
