(888) 312-8812 Login Signup| Outside Diameter Top | 3.563 |
| Inide Diameter Top | 1.898 |
| Outside Diameter Bottom | 3.563 |
| Collapse Pressure | 435 |
| Operating Temp Min F | -13 |
| Operating Temp Max F | 248 |
| Capacity gr | 77.0105875 |
| Filter Area sq in | 787 |
| Flow Direction | Outside-In |
| Gasket Material | Viton |
| Fluid Type | HH / HL / HM / HV |
| Beta Ratio 1 | 200/9.9 |
| Beta Ratio 2 | 1000/12.4 |
| Micron 1 | 10 |
| Brand | Part Number |
|---|---|
| HYDAC | 01250494 |
