WABCO part description

CONTROL, ANTI-LOCK BRAKE, VEHI

Product Attributes

Voltage 12 V
Calculated Volume (dmA) 2.265
Distance Between Holes 112x122 mm
Mounting 3x Ø 7.5 mm
Part Type Premium original quality
Product Category Device
Protection class IP 30 ( IEC 529 )
System 4S/4M
Technical specification OE specification
Temperature Range -40°C to +75°C
Type PABS ECU E4C

Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
