Bendix K091381 - R-14 Air Brake Relay Valve
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
BENDIX part description
BENDIX® AIR BRAKE RELAY VALVE
| Mounting: | 3/8-16 UNC-2B (3x) |
| Supply Port 1: | 1/2-14 NPT |
| Maximum Operating Temperature: | 200 °F (93 °C) |
| Minimum Operating Temperature: | -40 °F (-40 °C) |
| Exhaust Port: | Exhaust Adapter (without Silencer) |
| Mounting Orientation CW from Front Face: | 180° |
| Body Configuration: | 1 SUP / 8 DEL (6H + 2V) |
| Control Secondary Service Port: | 1/4-18 NPT |
| Delivery Port 1: | 1/2-14 NPT |
| Delivery Port 2: | 1/2-14 NPT |
| Delivery Port 3: | 1/2-14 NPT |
| Delivery Port 4: | 1/2-14 NPT |
| Delivery Port 5: | Cored Closed |
| Crack Pressure: | 4.0 PSI |
| TMC Washer: | RV040 |
| Control Port Orientation CW from Front Face: | 0° |
| Balance Primary Service Port: | 1/8-27 NPT (with Cover) |
| Delivery Port 6: | Cored Closed |
| Delivery Port 7: | 3/8-18 NPT (Plugged) |
| Delivery Port 8: | 3/8-18 NPT (Plugged) |
| Product Type | Relay Valve |
| Valve Type | R-14 |
A part of the Knorr-Bremse Group, Bendix® provides the automotive and truck parts industry with cutting-edge energy management solutions, active safety technologies, and air brake charging for tractors, buses, commercial vehicles, trailers, as well as medium- and heavy-duty trucks throughout North America. Headquartered in Elyria, Ohio, Bendix Commercial Vehicle Systems employs over 3,200 people who work hand in hand for the accomplishment of the brand's vision: "to become the leading worldwide supplier of active vehicle safety systems within the commercial vehicle industry." This brand takes pride in being the first to introduce many notable parts and technologies to the North American commercial vehicle market. Among these many firsts are the groundbreaking air brake system technologies such as air dryers, air compressors, and ABS. At Bendix, exceeding industry standards is a strict requirement.
