Standard Ignition S2502 - Multi Function Connector
- Part Number
- S2502
- Manufacturer
- STANDARD IGNITION
- Description
-
Multi Function Connector
details
$4899
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
STANDARD IGNITION part description
Product Description
Multi Function Connector
Features & Benefits
- Protective Tubing Included
- Each part has high-quality direct replacement electrical connector that eliminates the need for a harness, replacing only the damaged connector, for a cost effective repair solution
- The terminals are manufactured with high grade materials such as copper alloy, brass, and phosphor bronze.
- The Housing is fabricated using polyamide resins. All of the materials together provide the connectors with prolonged life and superior performance in harsh environments.
- All electrical connectors are 100% tested for proper mechanical and electrical fit, form and function.
- Offering thousands of high-quality pigtails and sockets for nearly every electrical job.
Product Attributes
| Attachment Method | Push On |
| Bend Angle (Deg.) | 0 |
| Connector Gender | Male |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Contact Terminal Material | Metal |
| Dust Shield Included | No |
| Length - Inches | 1 |
| Material | Plastic |
| Number Of Splice Connectors Includ | 2 |
| Number of Wires | 2 |
| Splice Connectors Included | Yes |
| Terminal Gender | Female |
| Terminal Quantity | 2 |
| Terminal Type | Blade |
| Water Resistant | Yes |
| Weatherproof Sealed | Yes |
| Wire Gauge (ga) | 20 |
| Wire Quantity | 2 |
| Wiring Harness Included | Yes |
| Wiring Harness Length (in) | 19 |
| Wiring Harness Length (mm) | 482.6 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8536908585 |
| Warranty Distance | 36000 |
| Warranty Distance UOM | MI |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| UPC | 00033086572635 |
Part Interchanges
Fits Vehicles
- Buick Regal Sportback (2018-2019)
- GMC Terrain (2018-2024)
- Cadillac XTS (2018-2019)
- Chevrolet Equinox (2018-2024)
- Buick Envision (2016-2020)
- Chevrolet S10 (2016-2017)
- GMC Acadia (2017-2019)
- Cadillac XT5 (2017-2018)
- Buick LaCrosse (2017-2019)
- Chevrolet Cruze (2016-2019)
- Cadillac CT6 (2016-2019)
- Chevrolet Spark (2016-2022)
- Chevrolet Camaro (2016-2019)
- Chevrolet Malibu Limited (2016)
- Chevrolet Colorado (2015-2019)
- GMC Canyon (2015-2019)
- Cadillac CTS (2014-2017)
- Buick Regal (2014-2017)
- Chevrolet Impala (2014-2015)
- Cadillac ATS (2013-2019)
- Chevrolet Malibu (2013-2023)
