(888) 312-8812 Login SignupGATES G43334-5656 Code 61 Captive O-Ring Flange - 45 Bent Tube (GL)
$76799
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 13
GATES G43334-5656 Part Description
Manufacturer
Product Description
Code 61 Captive O-Ring Flange - 45 Bent Tube (GL)
Features & Benefits
- Designed for larger-diameter hoses - up to 4 in. I.D.
- Designed for larger-diameter hoses – up to 4 in. I.D.
- Short body length provides the necessary grip for low pressure hose requirements
- Bubble pattern crimp design ensures optimal sealing to helical wire hoses on return vacuum applications
GATES G43334-5656 Specifications
Product Attributes
| Coupling Description | GL Code 61 Captive O-Ring Flange - 45 Bent Tube |
| Industrial Description | 56GL-56FLCF45-054 |
| Inside Diameter | 3.5 IN |
| Hydraulic Hose Recommendation | Gates GMV, MegaTech G5TB, MegaTech 500 |
| Flange Thickness | .42 in |
| Flange Diameter | 4.5 IN |
| Drop Length | 2.13 IN |
| Cut-Off Length | 6.02 IN |
| Length | 9.67 IN |
| Inside Diameter | 88.9 MM |
| Flange Thickness | 10.7 MM |
| Flange Diameter | 114.3 MM |
| Drop Length | 54.1 MM |
| Cut-Off Length | 152.9 MM |
| Length | 245.6 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| Country of Origin (Primary) | US |
| UPC | 00770075610342 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G43334-5656 Part Interchanges
| Brand | Part Number |
|---|---|
| NAPA | G43334-5656 |
