DELPHI part description

Product Description

Control Arm and Ball Joint Assembly

Product Attributes

Item Grade Standard Replacement
Position(s) Front Left Lower
Pre-Greased Yes
Grease Fitting Included No
Bushings Included Yes
Ball Joint Mounting Type Bolt In
Ball Joint Stud Type Threaded
Control Arm Construction Stamped
Control Arm Material Steel
Mounting Hardware Included Yes
Mounting Hole Quantity 3
Adjustable No
Greasable No
Control Arm Maximum Width 575.30 MM
Control Arm Color Black
Control Arm Maximum Length 330.30 MM
Bushing Material Rubber
Mounting Hole Diameter 16.50 MM
Thread Direction Clockwise (Right)
Bushing Color Black
Dust Boot Included Yes
Ball Joint Included Yes
Grade Type Premium
Boot Material Chloroprene Rubber (CR)
Locking Nut Included Yes
Boot Color Black
Steering Type Power
Bearing Material Plastic
Dust Boot Material Chloroprene Rubber (CR)
Control Arm Maximum Width 22.650 IN
Control Arm Maximum Length 13.004 IN
Mounting Hole Diameter 0.650 IN

Additional Information

Harmonized Tariff Code (Schedule B) 8708806590
Harmonized Tariff Code (HTS) 8708807000
Warranty Special Limited Lifetime
Warranty Special UOM LF
Country of Origin (Primary) CN
UPC 00689604351178
VMRS Code 016001001
UNSPSC 25172013

Part Interchanges

Fits Vehicles

  • Chevrolet Colorado (2004-2012)
  • GMC Canyon (2004-2012)
