DELPHI TC6390 Part Description
DELPHI TC6390 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Upper |
| Material | Steel |
| Color | Black |
| Stud Thread Diameter | 0.5 IN |
| Castle Nut Included | Yes |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 62 MM |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Mounting Bolt Length | 0.984 IN |
| Mounting Bolt Length | 25.00 MM |
| Washers Included | No |
| Height | 4.252 IN |
| Nuts Included | Yes |
| Mounting Hole Quantity | 4 |
| Adjustable | No |
| Greaseable | Yes |
| Stud Thread Length | 1.063 IN |
| Wrench Size | 13mm |
| Stud Type | Threaded |
| Mounting Type | Bolt-In |
| Dust Boot Material | Rubber |
| Mounting Bolt Shank Diameter | 0.313 IN |
| Mounting Bolt Head Diameter | 0.571 IN |
| Mounting Bolt Head Diameter | 14.50 MM |
| Mounting Bolts Included | Yes |
| Mounting Bolt Threads Per Inch | 24 |
| Mounting Bolt Thread Length | 23.00 MM |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| Stud Taper Per Foot | 0.125 IN |
| Stud Tapered End 2 Diameter | 0.61 IN |
| Stud Tapered End 2 Diameter | 15.5 MM |
| Stud Tapered End 1 Diameter | 0.689 IN |
| Stud Tapered End 1 Diameter | 17.5 MM |
| Stud Threads Per Inch | 18 |
| Length | 81.00 MM |
| Length | 3.190 IN |
| Stud Thread Diameter | 12.7 MM |
| Height | 108.00 MM |
| Stud Thread Length | 27 MM |
| Mounting Bolt Shank Diameter | 7.95 MM |
| Mounting Bolt Thread Length | 0.910 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708807000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708806590 |
| Country of Origin (Primary) | TR |
| UPC | 00689604341575 |
| VMRS Code | 016001014 |
| UNSPSC | 25174203 |
DELPHI TC6390 Part Interchanges
| Brand | Part Number |
|---|---|
| MOOG Chassis Products | K3082 |
| American Motors | 3236414, 4487652, 4488667, 8121302 |
| TRW | JBJ556 |
| N/A | MK3082, 8130792, B3082PR, GK3082, B3082 |
DELPHI TC6390 Fits Vehicles
- American Motors Rebel (1970)
- American Motors Javelin (1969-1974)
- American Motors Ambassador (1970-1974)
- American Motors Spirit (1979-1983)
- American Motors Matador (1971-1978)
- American Motors Gremlin (1970-1978)
- American Motors Hornet (1970-1977)
- American Motors Eagle (1980-1988)
- American Motors Concord (1978-1983)
- American Motors AMX (1970, 1978-1980)
