Name: Delphi TA6311 Tie Rod End
SKU: ta6311
Price: 45.99 USD
Availability: InStock

DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s)	Inner
Item Grade	Standard Replacement
Length	242.90 MM
Color	Black and Silver
End 1 Gender	Male
End 2 Gender	Male
Pre-Greased	Yes
Grease Fitting Included	No
Dust Boot Included	No
Width	35 MM
Type	Straight
Mounting Hardware Included	Yes
End 2 Thread Diameter	14.00 MM
Height	35.00 MM
Grade Type	Standard
Housing Material	Steel
Tube Diameter	18.00 MM
Adjustable	No
Greasable	No
Weight	1.07 lb
Bearing Material	Plastic
End 1 Thread Direction	Clockwise (Right)
End 2 Thread Direction	Clockwise (Right)
Grade	Premium
Stud Type	Threaded
Head Drive Type	Hex
End 2 Thread Pitch	1.5 MM
End 1 Thread Pitch	1.5 MM
Length Stud Center to End	225.40 MM
Tie Rod Material	Steel
End 1 Thread Diameter	16.00 MM
End 2 Thread Diameter	0.551 IN
36	0.710 IN
Length Stud Center to End	8.874 IN
End 1 Thread Diameter	0.630 IN

Additional Information

Harmonized Tariff Code (Schedule B)	8708947550
Harmonized Tariff Code (HTS)	8708947550
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Country of Origin (Primary)	TW
UPC	00689604351529
VMRS Code	015004070
UNSPSC	25174205

Part Interchanges

Fits Vehicles

Toyota 86 (2017-2020)
Subaru BRZ (2013-2020, 2022)
Scion FR-S (2013-2016)
