Name: Delphi TA5617 Tie Rod End
SKU: ta5617
Price: 22.99 USD
Availability: InStock

DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s)	Left Outer
Item Grade	Standard Replacement
Length	240.00 MM
Color	Black
End 1 Gender	Male
End 2 Gender	Female
Pre-Greased	Yes
Grease Fitting Included	No
Dust Boot Included	No
Width	65 MM
Type	Bent
Mounting Hardware Included	Yes
End 2 Thread Diameter	0.551 IN
End 2 Thread Diameter	14.00 MM
Height	89.90 MM
Housing Material	Steel
Adjustable	No
Greasable	No
Weight	1.14 lb
662	0.539 IN
Cone Outside Diameter	13.70 MM
Bearing Material	Plastic
End 1 Thread Direction	Clockwise (Right)
End 2 Thread Direction	Clockwise (Right)
Grade	Premium
Stud Type	Threaded
End 2 Thread Pitch	1.5 MM
End 1 Thread Pitch	1.25 MM
Length Stud Center to End	2.165 IN
Length Stud Center to End	55.00 MM
Dust Boot Material	Rubber
Tie Rod Material	Steel
End 1 Thread Diameter	0.472 IN
End 1 Thread Diameter	12.00 MM
Shank Length	13.70 MM
Stud Length	13.70 MM
Grade Type	Standard
Boot Color	Black
Shank Length	0.539 IN
Stud Length	0.539 IN

Additional Information

Harmonized Tariff Code (HTS)	8708947550
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Harmonized Tariff Code (Schedule B)	8708947550
Country of Origin (Primary)	CN
UPC	00689604314593
VMRS Code	015004020
UNSPSC	25174205

Part Interchanges

Fits Vehicles

Acura TLX (2015-2020)
Honda Accord (2013-2017)
