(888) 312-8812 Login SignupDELPHI AF10431 Mass Air Flow Sensor
$20149
Limited availability at this price!
In Stock
Get it by Friday, Dec 26
DELPHI AF10431 Part Description
DELPHI AF10431 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Package Contents | Mass Air Flow Sensor - Probe Only |
| Color | Black and Silver |
| Housing Included | No |
| Terminal Type | Pin |
| Mounting Hardware Included | No |
| Universal Or Specific Fit | Specific |
| Grade Type | Regular |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Mounting Hole Quantity | 2 |
| Terminal Quantity | 6 |
| Connector Gender | Female |
| Terminal Gender | Male |
| Wiring Harness Included | No |
| Mounting Type | Bolt-On |
| Mounting Bracket Included | No |
| Sensor Casing Length | 65 MM |
| Sensor Casing Width | 62 MM |
| Voltage | 12.0 2H |
| Gasket Or Seal Included | Yes |
| Bolt Hole Center To Bolt Hole Center | 48.00 MM |
| Mounting Hole Diameter | 0.1 IN |
| Seal Outside Diameter | 33.7 mm |
| Seal Quantity | 1 |
| Sensor Casing Length | 2.5 IN |
| Sensor Casing Width | 2.4 IN |
| Bolt Hole Center To Bolt Hole Center | 1.80 IN |
| Mounting Hole Diameter | 4.5 MM |
| Seal Outside Diameter | 1.3 IN |
Additional Information
| Warranty Distance UOM | DH |
| Warranty Distance | 12000 |
| Harmonized Tariff Code (Schedule B) | 9026800000 |
| Warranty Time UOM | MO |
| Warranty Time | 12 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 9026802000 |
| UPC | 00689604300305 |
| VMRS Code | 045021019 |
| UNSPSC | 41111931 |
DELPHI AF10431 Part Interchanges
| Brand | Part Number |
|---|---|
| Motorcraft | AFLS-179 |
| Ford | 7C3Z 12B579-A |
| CARDONE Reman | 74-50066 |
| Standard Motor Products | MAS0383 |
| NAPA Reman Computers | XTP450066 |
| Blue Streak Electronics New | MF21279N |
| N/A | 5S9139, MF21279 |
DELPHI AF10431 Fits Vehicles
- Ford F-550 Super Duty (2008-2010)
- Ford F-450 Super Duty (2008-2010)
- Ford F-350 Super Duty (2008-2010)
- Ford F-250 Super Duty (2008-2010)
