WABCO 9607310750 - Tire Pressure Monitoring System (TPMS) Control Module - IVTM Wheel Module
$17149
MSRP: $214.18
Save: $42.69
Limited Availability
Pay over 3-12 months with
. Learn more
. Learn more
WABCO part description
IVTM Wheel Module
Product Attributes
| Weight | 0.6305 |
| Calculated Volume (dm³) | 0.7934 |
| Size | 114 x 174 x 40 |
| Operational Range | 2 to 14 bar |
| Diameter | 285.8 mm |
| Port Angle | 170° |
| Protection class | IP 6K6K / 6K7 / 6K9K |
| Type | Wheel Modul 2 |
| Port thread 2 | Voss 203 Ø 6 x 1.5 |
| Angle Between Holes | 36° |
| Mounting | 2x Ø 26 mm |
| Port thread 1 | VG 8 |
| Temperature Range | -40°C to +90°C |
| Angle | 33° |
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
