(888) 312-8812 Login SignupWABCO 9253920030 Air Brake Chamber - Double Diaphragm Tristop 30/30
Tap to view 3 more
MSRP: $172.05
$10449
Save $67.56
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 13
WABCO 9253920030 Part Description
WABCO 9253920030 Specifications
Product Attributes
| Size | 100 x 200 x 300 |
| Distance between bolts | 120.6 mm |
| Max. operating pressure | 145.0 psi |
| Port thread 11 | 3/8" - 18 NPTF |
| Port Angle | 135° |
| Weight | 20.6 |
| Stroke | 75.9 mm |
| Type | 30/30 |
| Version | Without boot |
| Total Length | 363.0 mm |
| Port thread 12 | 3/8" - 18 NPTF |
| Clevis Pins | 12.9 mm |
| Release Pressure | 4.6 bar |
| Type Of Operation | Cam |
| Bolt Lengths | 38.0 mm |
| Temperature Range | -40°C to +80°C |
| Bolt Threads | 5/8'' - 11 UNC |
| Calculated Volume (dm³) | 6 |
| Push-Rod Length | 90.2 mm |
WABCO 9253920030 Cross References
We have 1 alternatives for the 9253920030 by WABCO:
WABCO 9253920030 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 9253920030 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
