WABCO 4721951000 - ABS Solenoid Modulator Valve
$45299
MSRP: $853.13
Save: $400.14
Limited Availability
. Learn more
WABCO part description
Product Attributes
| Calculated Volume (dmA) | 1.1067 |
| Distance Between Holes | 71x20 mm |
| Electrical connection | Bayonet ISO 15 170 A1-3.1-Sn/K1 |
| Exhaust | With external silencer 432 407 070 0 |
| Max. operating pressure | 11.0 bar |
| Mounting | 2x Ø 8.5 mm |
| Part Type | Premium original quality |
| Port thread 1 | 1/2"-14 Dry seal NPTF |
| Port thread 2 | 1/2" - 14 Dry Seal NPTF |
| Product Category | Device |
| Protection class | IP 66 / 69 K |
| Rated current | 2220 mA |
| Technical specification | OE specification |
| Temperature Range | -40°C to +80°C |
| Voltage | 12 V |
WABCO 4721951000 Cross Reference
We have 6 alternatives for the 4721951000 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
