(888) 312-8812 Login SignupWABCO 9730110110 Air Brake Relay Valve
Tap to view 3 more
MSRP: $731.05
$61049
Save $120.56
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 9730110110 Part Description
WABCO 9730110110 Specifications
Product Attributes
| Max. operating pressure | 145.04 psi |
| Opening Pressure | 0.5 bar |
| Temperature Range | -40°C to +80°C |
| Size | 98 x 103 x 109 |
| Max. operating pressure | 145.04 psi |
| Weight | 1.2985 |
| Port thread 4 | M16 x 1.5 |
| Port thread 2 | 2x M22 x 1.5 |
| Version | Pressure reduction |
| Predominance | 0.10 bar |
| Exhaust | Snap on contour JED - 463 |
| Port thread 3 | JED-463 |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Regulating Ratio | 1:1 |
| Calculated Volume (dm³) | 1.1002 |
WABCO 9730110110 Cross References
We have 1 alternatives for the 9730110110 by WABCO:
WABCO 9730110110 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 9730110110 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
