WABCO 9121250000 - Air Brake Compressor - Single-Cylinder compressor, Flange Mounted
$1,92099
MSRP: $3,576.50
Save: $1,655.51
Limited Availability
. Learn more
WABCO part description
Product Description
COMPRESSOR 238C
Product Attributes
| Piston stroke | 42 mm |
| Calculated Volume (dm³) | 10.5853 |
| Swept Volume (Cm³) | 238 cm3 |
| Max. operating pressure | 12.0 bar |
| Max. operating pressure | 174 psi |
| Port Thread 9 | 2x 1/2" - 14 NPTF |
| Port Thread 0 | 3/4" - 14 NPTF |
| Weight | 30.8911 |
| Port thread 2 | 3/4" - 14 NPTF |
| Piston Diameter | 85.0 mm |
| Size | 303 x 255 x 137 |
| Operating speed | 3000 (1/min) |
| Mounting | Flange mounting |
| Port Thread 8.1 | M10 x 1 |
| Lubrication | Lubrication supplied from engine |
| Type Of Operation | High pressure using unloader |
| Crankshaft thread | M18 x 1.5 |
| Cooling | Water |
| Type | Single Cylinder |
WABCO 9121250000 Cross Reference
We have 1 alternatives for the 9121250000 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
