Delphi FG2176 - Fuel Pump Module Assembly
$53649
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
DELPHI part description
Product Description
Fuel Pump Module Assembly
Product Attributes
Fuel Type | Flex |
Package Contents | Fuel Pump Module Assembly w/Float Arm, Seals, Instruction Sheet |
Item Grade | Standard Replacement |
Vapor Pressure Sensor | Yes |
System Pressure | 84 psi |
Fuel Level Sender Assembly Included | Yes |
Outlet Outside Diameter | 0.375 IN |
Voltage | 12 2H |
Regulator Included | Yes |
Maximum Pressure | 87 PS |
Terminal Type | Blade |
Gasket Or Seal Included | Yes |
Terminal Quantity | 4 |
Lock Ring Included | No |
Terminal Gender | Male |
Strainer Included | Yes |
Inlet Type | Strainer |
Outlet Type | Quick Connect |
Outlet Quantity | 3 |
In Tank or External | In Tank |
Resistance Ohms Empty | 250 82 |
Resistance Ohms Full | 40 82 |
Internal Or External Strainer | Internal |
Pump Type | Electric |
Average Current Draw | 18 68 |
Average Flow Rating | 42 GPH |
Fuel Sending Unit Included | Yes |
Negative Ground | No |
Fuel Type | Flex |
Mounting Hardware Included | No |
Grade Type | Premium |
Connector Quantity | 1 |
Connector Shape | Oval |
Housing Material | Plastic |
Installation Warnings | No |
Connector Gender | Female |
Fuel Filter Included | Yes |
Gasket Or Seal Material | Nitrile Rubber |
Minimum Pressure | 50 PS |
Wire Harness Included | No |
Pump Design | Turbine |
Fuel Tank Pressure Sensor Included | Yes |
Additional Information
Harmonized Tariff Code (HTS) | 9026204000 |
Warranty Special | Limited Lifetime |
Warranty Special UOM | LF |
Harmonized Tariff Code (Schedule B) | 8413309000 |
Country of Origin (Primary) | CN |
UPC | 00689604295731 |
VMRS Code | 044003258 |
UNSPSC | 25172409 |
Part Interchanges
Fits Vehicles
- GMC Savana 1500 (2010-2014)
- Chevrolet Express 1500 (2010-2014)
