Centric 120.52005 - Centric Premium Brake Rotor
$11099
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Vane Style [cntrc] | Pillar |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Kgs | 8.120 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] In | 6.213 |
| OEM Vane Count [cntrc] | 93 |
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] Mm | 157.800 |
| Weight [cntrc] Lbs | 17.900 |
| Discard Thickness | 0.709 IN |
| Discard Thickness | 18.000 MM |
| Nominal Thickness | 0.787 IN |
| Nominal Thickness | 20.000 MM |
| Hat Finish | Coated |
| Overall Height | 47.100 MM |
| Overall Height | 1.854 IN |
| Outside Diameter | 335.000 MM |
| Outside Diameter | 13.189 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 70.100 MM |
| Center Hole Diameter | 2.760 IN |
| Mounting Bolt Hole Circle Diameter | 4.488 IN |
| Mounting Bolt Hole Circle Diameter | 114.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.646 IN |
| Stud/Lug Hole Diameter | 16.400 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590334111 |
Part Interchanges
Fits Vehicles
- Tesla 3 (2017-2022)
