(888) 312-8812 Login SignupSTANDARD IGNITION S2472 Oil Pressure Switch Connector
Tap to view 3 more
SHIPS TODAY
$4999
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
STANDARD IGNITION S2472 Part Description
Manufacturer
Product Description
Oil Pressure Switch Connector
Features & Benefits
- Heat shrink butt connectors included
- Each part has high-quality direct replacement electrical connector that eliminates the need for a harness, replacing only the damaged connector, for a cost effective repair solution
- The terminals are manufactured with high grade materials such as copper alloy, brass, and phosphor bronze.
- The Housing is fabricated using polyamide resins. All of the materials together provide the connectors with prolonged life and superior performance in harsh environments.
- All electrical connectors are 100% tested for proper mechanical and electrical fit, form and function.
- Offering thousands of high-quality pigtails and sockets for nearly every electrical job.
STANDARD IGNITION S2472 Specifications
Product Attributes
| Attachment Method | Push On |
| Bend Angle (Deg.) | 0 |
| Connector Gender | Male |
| Connector Quantity | 1 |
| Connector Shape | Round |
| Contact Terminal Material | Metal |
| Dust Shield Included | No |
| Length - Inches | 1.25 |
| Material | Plastic |
| Number Of Splice Connectors Includ | 3 |
| Number of Wires | 3 |
| Splice Connectors Included | Yes |
| Terminal Gender | Female |
| Terminal Quantity | 3 |
| Terminal Type | Blade |
| Water Resistant | Yes |
| Weatherproof Sealed | Yes |
| Wire Gauge (ga) | 14 |
| Wire Quantity | 3 |
| Wiring Harness Included | Yes |
| Wiring Harness Length (in) | 16.5 |
| Wiring Harness Length (mm) | 419.1 |
| Terminal Quantity | 3 |
| Connector Gender | Male |
| Terminal Gender | Female |
Additional Information
| Country of Origin (Primary) | TW |
| Harmonized Tariff Code (HTS) | 8536908585 |
| Warranty Distance | 36000 |
| Warranty Distance UOM | MI |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| UPC | 00033086554853 |
STANDARD IGNITION S2472 Part Interchanges
| Brand | Part Number |
|---|---|
| Echlin | EC2374 |
| ACDelco | PT3753 |
| BWD | PT2457 |
| Duralast | 1P2671 |
| General Motors | 13501882, 19368110 |
| Airtex | 1P2671 |
| N/A | PTA2952, PT3753 |
STANDARD IGNITION S2472 Fits Vehicles
- Hummer H2 (2009)
- Cadillac Escalade EXT (2009-2013)
- Cadillac Escalade ESV (2009-2014)
- Chevrolet Silverado 2500 (2011-2013)
- Chevrolet Colorado (2010-2012)
- GMC Sierra 3500 HD (2009-2016)
- Chevrolet Caprice (2011-2017)
- GMC Sierra 2500 HD (2009-2019)
- GMC Canyon (2009-2012)
- Chevrolet Silverado 3500 HD (2009-2016)
- Cadillac Escalade (2009-2014)
- Chevrolet Camaro (2010-2015)
- GMC Envoy (2009)
- GMC Sierra 1500 (2009-2013)
- Chevrolet Trailblazer (2009)
- Hummer H3T (2009-2010)
- Chevrolet Avalanche (2009-2013)
- Buick LaCrosse (2009)
- Chevrolet Impala (2009)
- GMC Savana 2500 (2009-2017)
- GMC Savana 3500 (2009-2017)
- GMC Yukon XL 2500 (2009-2013)
- GMC Yukon XL 1500 (2009-2014)
- GMC Yukon (2009-2014)
- Chevrolet Tahoe (2009-2013)
- Chevrolet Suburban 1500 (2009-2013)
- Chevrolet Suburban 2500 (2009-2013)
- Chevrolet Express 3500 (2009-2017)
- Chevrolet Express 2500 (2009-2017)
- Chevrolet Express 1500 (2009-2014)
- Hummer H3 (2009-2010)
- Chevrolet Silverado 2500 HD (2009-2016)
- GMC Savana 1500 (2009-2014)
- Cadillac CTS (2009-2014)
- Chevrolet Silverado 1500 (2009-2013, 2016-2017)
- Pontiac G8 (2009)
- Chevrolet Corvette (2009-2013)
