BENDIX part description

Product Description

Drum

Features & Benefits

  • Manufactured globally in ISO 9001/TS 16949-certified production facilities to meet strict OE specifications
  • With heat-resistant coating for maximum corrosion resistance and extended drum life
  • Built to offer ease of installation to save you lots of time
  • Provides lasting braking aid that tops life expectancy of many OEM drums
  • Helps prevent unexpected breakdowns and save maintenance cost

Courtesy of Bendix – All rights reserved

Bendix Brake Drum

Get improved stopping power and enhanced vehicle performance even in harsh weather with the Bendix brake drum. This product is proven to withstand severe duty performance as it is engineered to offer superior thermal stability and strength.

Product Attributes

Maximum Brake Diameter (Discard) 11.06 in.
Bolt Hole Quantity 6
Outside Diameter 12.4 in.
Mounting Hole Diameter 5-1/2 in.
Nominal Drum Diameter 10.99 in.
Bolt Hole Diameter 0.452 in
Height 3.06 in.
Location Front

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (HTS) 8708305020
VMRS Code 013017006
A part of the Knorr-Bremse Group, Bendix® provides the automotive and truck parts industry with cutting-edge energy management solutions, active safety technologies, and air brake charging for tractors, buses, commercial vehicles, trailers, as well as medium- and heavy-duty trucks throughout North America. Headquartered in Elyria, Ohio, Bendix Commercial Vehicle Systems employs over 3,200 people who work hand in hand for the accomplishment of the brand's vision: "to become the leading worldwide supplier of active vehicle safety systems within the commercial vehicle industry." This brand takes pride in being the first to introduce many notable parts and technologies to the North American commercial vehicle market. Among these many firsts are the groundbreaking air brake system technologies such as air dryers, air compressors, and ABS. At Bendix, exceeding industry standards is a strict requirement.
