Delphi TC3549 - Control Arm and Ball Joint Assembly
$10499
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Control Arm and Ball Joint Assembly
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Upper Forward |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Stud Type | Threaded |
| Control Arm Material | Aluminum |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 2 |
| Adjustable | No |
| Greasable | No |
| Control Arm Maximum Width | 12.598 IN |
| Control Arm Maximum Width | 320.00 MM |
| Control Arm Color | Gray |
| Ball Joint Thread Diameter | 0.472 IN |
| Ball Joint Thread Diameter | 12.00 MM |
| Ball Joint Stud Length | 0.945 IN |
| Ball Joint Stud Length | 24.00 MM |
| Control Arm Maximum Length | 8.032 IN |
| Control Arm Maximum Length | 204.00 MM |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Uncoated |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Control Arm Construction | Casting/Forged |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 12.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Bushing Material | Rubber |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.472 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604298695 |
| VMRS Code | 016001002 |
| UNSPSC | 25172013 |
Part Interchanges
Fits Vehicles
- Jaguar XJR575 (2018-2019)
- Jaguar XJR (2014-2017)
- Jaguar F-Type (2014-2016)
- Jaguar XKR-S (2012-2015)
- Jaguar XJ (2010-2019)
- Jaguar XKR (2007-2015)
- Jaguar XK (2007-2015)
- Lincoln LS (2000-2006)
- Ford Thunderbird (2002-2005)
- Jaguar S-Type (2000-2002)
