Centric 320.63070F - Centric GCX Rotor with Full Coating
$6449
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Weight [cntrc] Lbs | 16.750 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] Mm | 207.200 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Max Pb Drum Dia [cntrc] In | 8.157 |
| Weight [cntrc] Kgs | 7.610 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 10.400 MM |
| Discard Thickness | 0.409 IN |
| Nominal Thickness | 12.000 MM |
| Nominal Thickness | 0.472 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 76.500 MM |
| Overall Height | 3.012 IN |
| Outside Diameter | 12.441 IN |
| Outside Diameter | 316.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 206.000 MM |
| Nominal Drum Diameter | 8.110 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.839 IN |
| Center Hole Diameter | 72.100 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.600 MM |
| Stud/Lug Hole Diameter | 0.654 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590392319 |
CENTRIC 320.63070F Cross Reference
We have 3 alternatives for the 320.63070F by CENTRIC:
Fits Vehicles
- Dodge Nitro (2007-2011)
- Jeep Liberty (2008-2012)
