Name: Delphi TC5759 Ball Joint
SKU: tc5759
Price: 19.49 USD
Availability: InStock

DELPHI part description

Product Description

Ball Joint

Product Attributes

Item Grade	Standard Replacement
Position(s)	Front Lower
Material	Steel
Maximum Outside Diameter	1.969 IN
Maximum Outside Diameter	50.00 MM
Color	Gray
Stud Thread Diameter	14 MM
Castle Nut Included	No
Grease Fitting Included	No
Suspension Grade Type	Standard
Bushings Included	No
Dust Boot Included	Yes
Ball Joint Assembly	Yes
Width	50 MM
Cotter Pin Included	No
Cotter Pin Hole	No
Mounting Hardware Included	Yes
Washers Included	No
Height	3.839 IN
Nuts Included	Yes
Adjustable	No
Greasable	No
4966	0.906 IN
Stud Type	Threaded
Mounting Type	Press-In
Dust Boot Material	Rubber
Mounting Bolts Included	No
Mount Plate Included	No
Tapered Stud	Yes
Stud Taper Per Foot	0.125 IN
9212	0.654 IN
Stud Tapered End 2 Diameter	16.6 MM
9213	0.787 IN
Stud Tapered End 1 Diameter	20 MM
Stud Thread Pitch	1.5 MM
Stud Thread Diameter	0.55 IN
Height	97.51 MM
Stud Thread Length	23.01 MM

Additional Information

Harmonized Tariff Code (Schedule B)	8708807000
Harmonized Tariff Code (HTS)	8708806590
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
Country of Origin (Primary)	TR
UPC	00689604311554
VMRS Code	016001015
UNSPSC	25174203

Part Interchanges

Fits Vehicles

Mitsubishi Eclipse (2006-2011)
Mitsubishi Galant (2004-2012)
