(888) 312-8812 Login SignupDELPHI TC5738 Control Arm and Ball Joint Assembly
Tap to view 11 more
$6949
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
DELPHI TC5738 Part Description
DELPHI TC5738 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Left Lower Forward |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Machined |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 1 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 3.031 IN |
| Control Arm Maximum Width | 77.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 14.00 MM |
| Ball Joint Stud Length | 69.00 MM |
| Control Arm Maximum Length | 16.012 IN |
| Control Arm Maximum Length | 406.70 MM |
| Mounting Hole Diameter | 14.20 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 14.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Ball Joint Thread Diameter | 0.551 IN |
| Ball Joint Stud Length | 2.717 IN |
| Thread Diameter | 0.551 IN |
| Mounting Hole Diameter | 0.559 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604312049 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC5738 Part Interchanges
| Brand | Part Number |
|---|---|
| MOOG Chassis Products | CK622225 |
| Chrysler | 4670 509AD, 4670 509AE, 4670 509AF, 4670509AG, 5168 653AA, 5168 653AB, 5168 653AC, 5168653AD |
| MAS Industries | CB81473, CB81473PR |
| Dorman | 522-801 |
| N/A | GS251123, CMS251123 |
DELPHI TC5738 Fits Vehicles
- Chrysler 300 (2011-2022)
- Dodge Charger (2011-2021)
- Dodge Challenger (2011-2021)
