Name: Delphi TC5649 Ball Joint
SKU: tc5649
Price: 13.99 USD
Availability: InStock

DELPHI part description

Product Description

Ball Joint

Product Attributes

Item Grade	Standard Replacement
Position(s)	Front Upper
Material	Steel
Maximum Outside Diameter	1.634 IN
Maximum Outside Diameter	41.50 MM
Color	Gray
Stud Thread Diameter	10 MM
Castle Nut Included	Yes
Grease Fitting Included	No
Suspension Grade Type	Standard
Bushings Included	No
Dust Boot Included	Yes
Ball Joint Assembly	Yes
Width	41.5 MM
Cotter Pin Included	Yes
Cotter Pin Hole	Yes
Mounting Hardware Included	Yes
Washers Included	No
Height	3.189 IN
Nuts Included	Yes
Adjustable	No
Greasable	No
4966	1.028 IN
Stud Type	Threaded
Mounting Type	Press-In
Dust Boot Material	Rubber
Mounting Bolts Included	No
Mount Plate Included	No
Tapered Stud	Yes
Stud Taper Per Foot	0.125 IN
9212	0.531 IN
Stud Tapered End 2 Diameter	13.5 MM
9213	0.591 IN
Stud Tapered End 1 Diameter	15 MM
Stud Thread Pitch	1.25 MM
Length	81.00 MM
Length	3.190 IN
Stud Thread Diameter	0.39 IN
Height	81.00 MM
Stud Thread Length	26.11 MM

Additional Information

Harmonized Tariff Code (Schedule B)	8708807000
Country of Origin (Primary)	TR
Harmonized Tariff Code (HTS)	8708806590
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
UPC	00689604307113
VMRS Code	016001014
UNSPSC	25174203

Part Interchanges

Fits Vehicles

Hyundai Azera (2006-2007)
Hyundai Sonata (2005-2007)
