Centric 320.63086F - Centric GCX Rotor with Full Coating
$10349
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Hat Id [cntrc] In | 7.128 |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 33.050 |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 15.000 |
| Hat Id [cntrc] Mm | 181.050 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Vane Style [cntrc] | Straight |
| Notes [cntrc] | Vented Hat |
| OEM Vane Count [cntrc] | 47 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 30.500 MM |
| Discard Thickness | 1.201 IN |
| Nominal Thickness | 32.000 MM |
| Nominal Thickness | 1.260 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 56.500 MM |
| Overall Height | 2.224 IN |
| Outside Diameter | 370.000 MM |
| Outside Diameter | 14.567 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.854 IN |
| Center Hole Diameter | 72.500 MM |
| Mounting Bolt Hole Circle Diameter | 114.600 MM |
| Mounting Bolt Hole Circle Diameter | 4.512 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.600 MM |
| Stud/Lug Hole Diameter | 0.654 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 889590392340 |
Part Interchanges
CENTRIC 320.63086F Cross Reference
We have 3 alternatives for the 320.63086F by CENTRIC:
Fits Vehicles
- Dodge Challenger (2017-2022)
- Chrysler 300 (2014-2021)
- Dodge Charger (2014-2022)
