Centric 320.62135C - Centric GCX HC Rotor with High Carbon Content and Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX HC Rotor with High Carbon Content and Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Hat Id [cntrc] Mm | 195.500 |
| Weight [cntrc] Lbs | 16.950 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Hat Id [cntrc] In | 7.697 |
| Vane Style [cntrc] | Straight |
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Kgs | 7.700 |
| Misc Holes [cntrc] | 1 |
| Discard Thickness | 21.000 MM |
| Discard Thickness | 0.827 IN |
| Nominal Thickness | 23.000 MM |
| Nominal Thickness | 0.906 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 48.000 MM |
| Overall Height | 1.890 IN |
| Outside Diameter | 12.402 IN |
| Outside Diameter | 315.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 201.200 MM |
| Nominal Drum Diameter | 7.921 IN |
| Bearings Included | No |
| Center Hole Diameter | 70.700 MM |
| Center Hole Diameter | 2.783 IN |
| Mounting Bolt Hole Circle Diameter | 115.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.528 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.000 MM |
| Stud/Lug Hole Diameter | 0.551 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590406603 |
Part Interchanges
CENTRIC 320.62135C Cross Reference
We have 2 alternatives for the 320.62135C by CENTRIC:
