Centric 320.61010F - Centric GCX Rotor with Full Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Inner Bearing # [cntrc] | 410.91013 |
| Misc Holes [cntrc] | 0 |
| Vane Style [cntrc] | Straight |
| Product Grade [cntrc] | Premium |
| Inner Seal # [cntrc] | 417.61000 |
| Weight [cntrc] Lbs | 21.800 |
| Weight [cntrc] Kgs | 9.910 |
| Outer Bearing # [cntrc] | 410.91012 |
| Disc Mounting [cntrc] | Hub & Rotor |
| Discard Thickness | 20.570 MM |
| Discard Thickness | 0.810 IN |
| Nominal Thickness | 22.230 MM |
| Nominal Thickness | 0.875 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Stud Thread Diameter | 0.500 IN |
| Overall Height | 105.600 MM |
| Overall Height | 4.157 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| 54 | 280.200 MM |
| Rotor Outside Diameter | 11.031 in |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 20.000 IN |
| Bearings Included | No |
| Center Hole Diameter | 70.500 MM |
| Center Hole Diameter | 2.776 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590390971 |
Part Interchanges
CENTRIC 320.61010F Cross Reference
We have 1 alternatives for the 320.61010F by CENTRIC:
Fits Vehicles
- Mercury Monarch (1975-1980)
- Mercury Comet (1974-1977)
- Lincoln Versailles (1977-1980)
- Ford Maverick (1974-1977)
- Ford Granada (1975-1980)
