CENTRIC part description

Product Description

Centric GCX HC Rotor with High Carbon Content and Partial Coating

Features & Benefits

  • RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs

Product Attributes

Weight [cntrc] Kgs 12.000
California Proposition 65 Text [cntrc] WARNING: Cancer and Reproductive Harm
Vane Style [cntrc] Straight
Product Grade [cntrc] Premium
Disc Mounting [cntrc] Floating
Weight [cntrc] Lbs 26.450
Misc Holes [cntrc] 5
Discard Thickness 27.000 MM
Discard Thickness 1.063 IN
Nominal Thickness 1.181 IN
Nominal Thickness 30.000 MM
Disc Finish Partially Coated
Hat Finish Coated
Overall Height 51.500 MM
Overall Height 2.028 IN
Outside Diameter 12.913 IN
Outside Diameter 328.000 MM
ABS Tone Ring Included No
Surface Type Smooth
Solid Or Vented Type Rotor Vented
Bearings Included No
Center Hole Diameter 2.677 IN
Center Hole Diameter 68.000 MM
Mounting Bolt Hole Circle Diameter 108.000 MM
Mounting Bolt Hole Circle Diameter 4.252 IN
Stud/Lug Hole Quantity 5
Stud/Lug Hole Diameter 16.700 MM
Stud/Lug Hole Diameter 0.657 IN

Additional Information

Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 889590406535

Part Interchanges

CENTRIC 320.39048C Cross Reference

We have 3 alternatives for the 320.39048C by CENTRIC:
