Centric 320.35002H - Centric GCX Rotor with Full Coating and High Carbon Content
$3699
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 4.620 |
| Weight [cntrc] Lbs | 10.170 |
| Misc Holes [cntrc] | 2 |
| Disc Mounting [cntrc] | Floating / DIH |
| Discard Thickness | 0.327 IN |
| Discard Thickness | 8.300 MM |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10.000 MM |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 71.500 MM |
| Overall Height | 2.815 IN |
| Outside Diameter | 279.000 MM |
| Outside Diameter | 10.984 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 160.000 MM |
| Nominal Drum Diameter | 6.299 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.638 IN |
| Center Hole Diameter | 67.000 MM |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 15.000 MM |
| Stud/Lug Hole Diameter | 0.591 IN |
Additional Information
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 889590387773 |
Part Interchanges
CENTRIC 320.35002H Cross Reference
We have 2 alternatives for the 320.35002H by CENTRIC:
Fits Vehicles
- Mercedes-Benz 560SL (1986-1989)
- Mercedes-Benz 560SEL (1986-1991)
- Mercedes-Benz 560SEC (1986-1991)
- Mercedes-Benz 500SEL (1984-1985)
- Mercedes-Benz 500SEC (1984-1985)
- Mercedes-Benz 420SEL (1986-1991)
- Mercedes-Benz 380SLC (1981)
- Mercedes-Benz 380SL (1981-1985)
- Mercedes-Benz 380SEL (1981-1983)
- Mercedes-Benz 380SEC (1982-1983)
- Mercedes-Benz 380SE (1984-1985)
- Mercedes-Benz 350SDL (1990-1991)
- Mercedes-Benz 350SD (1991)
- Mercedes-Benz 300TD (1979-1985)
- Mercedes-Benz 300SDL (1986-1987)
- Mercedes-Benz 300SD (1978-1985)
- Mercedes-Benz 300D (1975-1985)
- Mercedes-Benz 300CD (1978-1985)
- Mercedes-Benz 280E (1977-1981)
- Mercedes-Benz 280CE (1978-1981)
- Mercedes-Benz 450SLC (1973-1980)
- Mercedes-Benz 450SL (1973-1980)
- Mercedes-Benz 450SEL (1973-1980)
- Mercedes-Benz 450SE (1973-1976)
- Mercedes-Benz 300SEL (1965-1973, 1988-1991)
- Mercedes-Benz 300SE (1961-1966, 1988-1991)
- Mercedes-Benz 280SL (1968-1971)
- Mercedes-Benz 280SEL (1968-1973)
- Mercedes-Benz 280SE (1968-1973, 1977-1980)
- Mercedes-Benz 280S (1968-1971, 1975-1976)
- Mercedes-Benz 280C (1973-1976)
- Mercedes-Benz 280 (1973-1976)
- Mercedes-Benz 250SL (1967)
- Mercedes-Benz 240D (1974-1983)
- Mercedes-Benz 230 (1967-1969, 1974-1978)
- Mercedes-Benz 220D (1968-1973)
- Mercedes-Benz 220 (1968-1973)
- Mercedes-Benz 250SE (1966-1968)
- Mercedes-Benz 250S (1966-1968)
- Mercedes-Benz 230S (1967-1969)
- Mercedes-Benz 230SL (1967)
- Mercedes-Benz 250SEC (1966-1968)
- Mercedes-Benz 350SL (1972-1973)
- Mercedes-Benz 250C (1969-1973)
- Mercedes-Benz 250 (1968-1973)
