(888) 312-8812 Login SignupCENTRIC 320.34074H Centric GCX Rotor with Full Coating and High Carbon Content
Tap to view 4 more
$6399
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
CENTRIC 320.34074H Part Description
Manufacturer
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.34074H Specifications
Product Attributes
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 7.270 |
| Misc Holes [cntrc] | 1 |
| Weight [cntrc] Lbs | 16.000 |
| Disc Mounting [cntrc] | Floating / DIH |
| Discard Thickness | 18.400 MM |
| Discard Thickness | 0.724 IN |
| Nominal Thickness | 0.783 IN |
| Nominal Thickness | 19.900 MM |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 63.100 MM |
| Overall Height | 2.484 IN |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Nominal Drum Diameter | 185.000 MM |
| Nominal Drum Diameter | 7.283 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.953 IN |
| Center Hole Diameter | 75.000 MM |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.700 MM |
| Stud/Lug Hole Diameter | 0.579 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590387346 |
CENTRIC 320.34074H Part Interchanges
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 980379R, 980379 |
CENTRIC 320.34074H Fits Vehicles
- BMW 530i (2004-2007)
- BMW 525i (2004-2007)
- BMW 528i (2008-2010)
CENTRIC 320.34074H Cross References
We have 2 alternatives for the 320.34074H by CENTRIC:
