Centric 320.22016H - Centric GCX Rotor with Full Coating and High Carbon Content
$9949
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Full Coating and High Carbon Content
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron Formulation Enhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 12.000 |
| Weight [cntrc] Lbs | 26.400 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Misc Holes [cntrc] | 1 |
| Disc Mounting [cntrc] | Floating |
| Discard Thickness | 1.063 IN |
| Discard Thickness | 27.000 MM |
| Nominal Thickness | 29.900 MM |
| Nominal Thickness | 1.177 IN |
| Disc Finish | Fully Coated |
| Hat Finish | Coated |
| Overall Height | 76.100 MM |
| Overall Height | 2.996 IN |
| Outside Diameter | 13.543 IN |
| Outside Diameter | 344.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 78.900 MM |
| Center Hole Diameter | 3.106 IN |
| Mounting Bolt Hole Circle Diameter | 120.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.724 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.500 MM |
| Stud/Lug Hole Diameter | 0.650 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590386530 |
Part Interchanges
CENTRIC 320.22016H Cross Reference
We have 1 alternatives for the 320.22016H by CENTRIC:
Fits Vehicles
- Land Rover Range Rover (2006-2009)
