(888) 312-8812 Login SignupDELPHI TC5450 Control Arm and Ball Joint Assembly
Tap to view 5 more
$3399
Limited availability at this price!
In Stock
Get it by Thursday, Jan 15
DELPHI TC5450 Part Description
DELPHI TC5450 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Bushings Included | Yes |
| Ball Joint Mounting Type | Machined |
| Ball Joint Stud Type | Threaded |
| Control Arm Construction | Casting/Forged |
| Control Arm Material | Steel |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Maximum Width | 3.740 IN |
| Control Arm Maximum Width | 95.00 MM |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.472 IN |
| Ball Joint Thread Diameter | 12.00 MM |
| Ball Joint Stud Length | 2.244 IN |
| Ball Joint Stud Length | 57.00 MM |
| Control Arm Maximum Length | 15.354 IN |
| Control Arm Maximum Length | 390.00 MM |
| Bushing Material | Rubber |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 12.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.472 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | CN |
| UPC | 00689604296424 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC5450 Cross References
DELPHI TC5450 Fits Vehicles
- Saturn SW2 (1993-2001)
- Saturn SW1 (1993-1999)
- Saturn SL2 (1991-2002)
- Saturn SL1 (1991-2002)
- Saturn SL (1991-2002)
- Saturn SC (1991-1992)
- Saturn SC2 (1993-2002)
- Saturn SC1 (1993-2002)
