Delphi TA5474 - Tie Rod End Assembly
$2649
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Tie Rod End Assembly
Product Attributes
| Position(s) | Left |
| Item Grade | Standard Replacement |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Male |
| Finish | Cataphoresis |
| Grease Fitting Included | No |
| Dust Boot Included | Yes |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.551 IN |
| End 2 Thread Diameter | 14.0 MM |
| Adjustable | Yes |
| Greasable | No |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| End 2 Thread Pitch | 1.5 MM |
| End 1 Thread Pitch | 1.5 MM |
| Length Stud Center to End | 13.551 IN |
| Length Stud Center to End | 344.2 MM |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Tie Rod Material | Steel |
| End 1 Thread Diameter | 0.472 IN |
| End 1 Thread Diameter | 11.99 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708947550 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| UPC | 00689604302569 |
| VMRS Code | 015004024 |
| UNSPSC | 25174205 |
Part Interchanges
Fits Vehicles
- Volkswagen EuroVan (1993-1995)
