Name: Delphi TA5456 Tie Rod End
SKU: ta5456
Price: 21.49 USD
Availability: InStock

DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s)	Right, Right Outer. For the position specific to your vehicle, refer to the Applications.
Item Grade	Standard Replacement
Length	112.00 MM
Color	Black
End 1 Gender	Male
End 2 Gender	Male
Pre-Greased	Yes
Grease Fitting Included	Yes
Dust Boot Included	Yes
Width	48.4 MM
Type	Straight
Mounting Hardware Included	Yes
End 2 Thread Diameter	0.750 IN
End 2 Thread Diameter	19.05 MM
Height	81.80 MM
Housing Material	Steel
36	0.750 IN
Tube Diameter	19.05 MM
Adjustable	No
Greasable	Yes
Weight	1.32 lb
Cone Outside Diameter	17.90 MM
Bearing Material	Plastic
End 1 Thread Direction	Clockwise (Right)
End 2 Thread Direction	Clockwise (Right)
Stud Type	Threaded
Length Stud Center to End	3.543 IN
Length Stud Center to End	90.00 MM
Dust Boot Material	Rubber
Tie Rod Material	Steel
End 2 Threads Per Inch	16
End 1 Threads Per Inch	18
End 1 Thread Diameter	0.563 IN
End 1 Thread Diameter	14.29 MM
Shank Length	17.90 MM
Stud Length	17.90 MM
Grade Type	Standard
Grade	Premium
Shank Length	0.705 IN
Stud Length	0.705 IN
662	0.705 IN

Additional Information

Harmonized Tariff Code (Schedule B)	8708998175
Country of Origin (Primary)	TR
Harmonized Tariff Code (HTS)	8708998180
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
UPC	00689604302279
VMRS Code	015004019
UNSPSC	25174205

Part Interchanges

Fits Vehicles

International 1200A (1966)
International C122 (1961-1962)
International C120 (1961-1962)
International C1200 (1963-1964)
International A122 (1957-1958)
International A120 (1957-1958)
International 1200C (1968)
Ford F-350 (1953-1966)
Ford F-250 (1961-1966)
Ford F-100 (1961-1965)
GMC 1500 (1966)
GMC 2500 (1966)
GMC 1000 (1966)
GMC K1000 (1966)
GMC I1500 (1965-1966)
Ford F4 (1948-1952)
GMC K1000 Pickup (1966)
GMC Suburban (1963-1966)
GMC K15/K1500 Pickup (1966)
GMC 2500 Series (1963-1965)
GMC 1500 Series (1963-1965)
GMC 1000 Series (1963-1965)
Chevrolet Suburban (1964-1966)
Chevrolet K20 Pickup (1961-1966)
Chevrolet K10 Pickup (1964-1966)
Ford P-400 (1975-1976)
Ford P-500 (1975-1977)
Ford P-350 (1953-1976)
