Centric 320.35086 - Centric GCX Rotor with Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Disc Mounting [cntrc] | Floating |
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 9.820 |
| Weight [cntrc] Lbs | 21.600 |
| Vane Style [cntrc] | Curved |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 26.000 MM |
| Discard Thickness | 1.024 IN |
| Nominal Thickness | 1.106 IN |
| Nominal Thickness | 28.100 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 47.100 MM |
| Overall Height | 1.854 IN |
| Outside Diameter | 330.000 MM |
| Outside Diameter | 12.992 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 67.000 MM |
| Center Hole Diameter | 2.638 IN |
| Mounting Bolt Hole Circle Diameter | 112.500 MM |
| Mounting Bolt Hole Circle Diameter | 4.429 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.300 MM |
| Stud/Lug Hole Diameter | 0.524 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590424959 |
Part Interchanges
CENTRIC 320.35086 Cross Reference
We have 3 alternatives for the 320.35086 by CENTRIC:
