Centric 320.65061 - Centric GCX Rotor with Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Misc Holes [cntrc] | 0 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 230.000 |
| Weight [cntrc] Kgs | 10.000 |
| Weight [cntrc] Lbs | 22.000 |
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 9.055 |
| Discard Thickness | 0.472 IN |
| Discard Thickness | 12.000 MM |
| Nominal Thickness | 14.000 MM |
| Nominal Thickness | 0.551 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 79.800 MM |
| Overall Height | 3.142 IN |
| Outside Diameter | 13.150 IN |
| Outside Diameter | 334.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 228.500 MM |
| Nominal Drum Diameter | 8.996 IN |
| Bearings Included | No |
| Center Hole Diameter | 87.500 MM |
| Center Hole Diameter | 3.445 IN |
| Mounting Bolt Hole Circle Diameter | 150.000 MM |
| Mounting Bolt Hole Circle Diameter | 5.906 IN |
| Stud/Lug Hole Quantity | 7 |
| Stud/Lug Hole Diameter | 14.300 MM |
| Stud/Lug Hole Diameter | 0.563 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590425697 |
