Centric 320.61076 - Centric GCX Rotor with Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 230.000 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 0 |
| Max Pb Drum Dia [cntrc] In | 9.055 |
| Weight [cntrc] Kgs | 8.860 |
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Lbs | 19.500 |
| Discard Thickness | 0.472 IN |
| Discard Thickness | 12.000 MM |
| Nominal Thickness | 13.900 MM |
| Nominal Thickness | 0.547 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 56.300 MM |
| Overall Height | 2.217 IN |
| Outside Diameter | 333.800 MM |
| Outside Diameter | 13.142 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 8.992 IN |
| Nominal Drum Diameter | 228.400 MM |
| Bearings Included | No |
| Center Hole Diameter | 70.700 MM |
| Center Hole Diameter | 2.783 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 14.100 MM |
| Stud/Lug Hole Diameter | 0.555 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590425642 |
Part Interchanges
CENTRIC 320.61076 Cross Reference
We have 2 alternatives for the 320.61076 by CENTRIC:
