Centric 320.40052 - Centric GCX Rotor with Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Disc Mounting [cntrc] | Floating / DIH |
| Max Pb Drum Dia [cntrc] In | 6.732 |
| Max Pb Drum Dia [cntrc] Mm | 171.000 |
| Misc Holes [cntrc] | 5 |
| Weight [cntrc] Kgs | 4.550 |
| Weight [cntrc] Lbs | 10.000 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 7.300 MM |
| Discard Thickness | 0.287 IN |
| Nominal Thickness | 0.354 IN |
| Nominal Thickness | 9.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 66.100 MM |
| Overall Height | 2.602 IN |
| Outside Diameter | 282.000 MM |
| Outside Diameter | 11.102 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 170.000 MM |
| Nominal Drum Diameter | 6.693 IN |
| Bearings Included | No |
| Center Hole Diameter | 64.200 MM |
| Center Hole Diameter | 2.528 IN |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.600 MM |
| Stud/Lug Hole Diameter | 0.496 IN |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 889590388763 |
