Centric 121.66081 - C-Tek Standard Brake Rotor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 3 |
| Hat Id [cntrc] In | 7.760 |
| Weight [cntrc] Lbs | 18.550 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 197.100 |
| Weight [cntrc] Kgs | 8.420 |
| OEM Vane Count [cntrc] | 57 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 0.709 IN |
| Discard Thickness | 18.000 MM |
| Nominal Thickness | 20.000 MM |
| Nominal Thickness | 0.787 IN |
| Overall Height | 2.079 IN |
| Overall Height | 52.800 MM |
| Outside Diameter | 345.000 MM |
| Outside Diameter | 13.583 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 78.600 MM |
| Center Hole Diameter | 3.094 IN |
| Mounting Bolt Hole Circle Diameter | 5.500 IN |
| Mounting Bolt Hole Circle Diameter | 139.700 MM |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 15.900 MM |
| Stud/Lug Hole Diameter | 0.626 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590359275 |
Part Interchanges
CENTRIC 121.66081 Cross Reference
We have 3 alternatives for the 121.66081 by CENTRIC:
Fits Vehicles
- Cadillac Escalade ESV (2021-2023)
- Chevrolet Silverado 1500 LTD (2022)
- Cadillac Escalade (2021-2023)
- GMC Yukon (2021-2023)
- GMC Yukon XL (2021-2023)
- Chevrolet Suburban (2021-2023)
- Chevrolet Tahoe (2021-2023)
- GMC Sierra 1500 Limited (2019, 2022)
- GMC Sierra 1500 (2019-2023)
- Chevrolet Silverado 1500 (2019-2023)
