Dorman B5208XL - Suspension Ball Joint
$1949
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DORMAN part description
Product Description
Suspension Ball Joint
Application Summary
General Motors 2005-70, Isuzu 2000-96
Features & Benefits
- Extended-life construction - this ball joint is built with features to deliver smooth performance and extended durability for demanding drivers
- Superior ball stud - hardened ArmourGrade stud with highly polished EverSmooth ball
- Low-friction bearing - UltraFlow normalized forged housing with I.C.E. synthetic grease and low-friction polymer bearing
- Premium corrosion resistance - WeatherShield external coating to resist corrosion
Suspension, Ball, Joint, Joints, Balls, Suspensions
Product Attributes
| Material | Acero |
| Stud Thread Diameter | 0.5 IN |
| Castle Nut Included | Oui |
| Suspension Grade Type | Premium |
| Cotter Pin Hole | Oui |
| Mounting Hardware Included | Oui |
| Mounting Hole Quantity | 4 |
| Adjustable | Non |
| Greasable | Oui |
| Stud Type | Roscado |
| Mounting Type | Con perno |
| Dust Boot Material | Policloropreno |
| Attachment Type | Cono |
| Bearing Material | Polímero |
| Bolts/Studs Included | Oui |
| Package Contents | 4 Bolts |
| Thread Pitch | M20 |
| Length | 111 MM |
| Color | Gris |
| Width | 59 MM |
| Type | Roscado |
| Height | 85.03 MM |
| Wrench Size | 12 mm MM |
| Maximum Outside Diameter | 61 MM |
| Grease Fitting Included | Non |
| Bushings Included | Non |
| Dust Boot Included | Oui |
| Ball Joint Assembly | Oui |
| Cotter Pin Included | Non |
| Washers Included | Non |
| Nuts Included | Oui |
| Stud Thread Length | 35.5 MM |
| Bushing Quantity | 0 |
| Mounting Bolts Included | Non |
| Mount Plate Included | Non |
| Tapered Stud | Oui |
| Stud Taper Per Foot | 2 IN |
| Stud Tapered End 2 Diameter | 22 MM |
| Stud Tapered End 1 Diameter | 27.2 MM |
| Stud Thread Pitch | 1.5 MM |
| Articulación de rótula instalada | Sí |
| Ball Joint Installed | Oui |
| Bushing Included | Non |
| Contenidos del paquete | 4 tuercas, grasera, 1 tuerca de seguridad (tipo castillo), 1 pasador (chaveta), 4 pernos |
| Diámetro del acoplado a presión de la caja | 45mm mm |
| Housing Press Fit Diameter | 45 mm MM |
| Pernos/argollas incluidos | Sí |
| Thread Pitch | 20 mm mm |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 4016995010 |
| UPC | 00669810706429 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
Part Interchanges
- Delphi TC1602
- MOOG Chassis Products K5208
- XRF K5208
- ACDelco 45D0016
- ACDelco 46D0016A
- Mcquay-Norris FA688
- Mcquay-Norris FA688E
- Mcquay-Norris FA688GL
- Centric Parts 610.66005
- General Motors 3986009
- General Motors 6258152
- General Motors 8097671120
- General Motors 8889113870
- General Motors 88911387
- General Motors 9767112
- TRW JBJ7023
- Mevotech Supreme MK5208
- QuickSteer K5208
- Mevotech Original Grade GK5208
- Mevotech TTX TXK5208
- SYD K-5208
- SYD K5208
- XRF Chassis K5208
- General Motors 88965476
Fits Vehicles
- Pontiac GTO (1973)
- Chevrolet Kingswood (1971-1972)
- Chevrolet Chevelle (1973)
- Chevrolet Brookwood (1971-1972)
- Chevrolet Biscayne (1971-1972)
- Buick Centurion (1971-1973)
- Pontiac Laurentian (1976-1981)
- Pontiac Ventura (1975-1977)
- Pontiac Safari (1987-1989)
- Pontiac Phoenix (1977-1979)
- Pontiac Parisienne (1976-1986)
- Pontiac LeMans (1973-1981)
- Pontiac Grandville (1971-1975)
- Pontiac Grand Safari (1971-1978)
- Pontiac Grand Prix (1973-1987)
- Pontiac Grand LeMans (1975-1983)
- Pontiac Grand Am (1973-1975, 1978-1980)
- Pontiac Firebird (1970-1981)
- Pontiac Catalina (1971-1981)
- Pontiac Bonneville (1971-1986)
- Oldsmobile Vista Cruiser (1973-1975)
- Oldsmobile Toronado (1979-1985)
- Oldsmobile Omega (1975-1979)
- Oldsmobile Delta 88 (1971-1985)
- Oldsmobile Cutlass Supreme (1973-1988)
- Oldsmobile Cutlass Cruiser (1980-1983)
- Oldsmobile Cutlass Calais (1978-1984)
- Oldsmobile Cutlass Tiara (1976)
- Oldsmobile Cutlass Salon (1975-1980, 1985-1987)
- Oldsmobile Cutlass (1973-1981, 1985-1987)
- Oldsmobile Custom Cruiser (1975-1992)
- Oldsmobile 98 (1971-1984)
- GMC Sprint (1973-1977)
- GMC Safari (1985-2005)
- GMC Sonoma (1991-2003)
- GMC S15 (1982-1990)
- GMC Jimmy (1992-2001)
- GMC S15 Jimmy (1983-1991)
- GMC Caballero (1978-1987)
- Chevrolet S10 (1982-2003)
- Chevrolet Blazer (1995-2005)
- Chevrolet S10 Blazer (1983-1994)
- Chevrolet Nova (1975-1979)
- Chevrolet Monte Carlo (1973-1988)
- Chevrolet Malibu (1973-1983)
- Chevrolet Laguna (1973-1976)
- Chevrolet LLV (1987-1995)
- Chevrolet Impala (1971-1985, 1994-1996)
- Chevrolet El Camino (1973-1987)
- Chevrolet Caprice (1971-1996)
- Chevrolet Camaro (1970-1981)
- Chevrolet Bel Air (1971-1975, 1981)
- Chevrolet Astro (1985-2005)
- Cadillac Seville (1976-1985)
- Cadillac Brougham (1987-1992)
- Cadillac Fleetwood (1977-1986, 1993-1996)
- Cadillac Eldorado (1979-1985)
- Cadillac DeVille (1977-1984)
- Cadillac Commercial Chassis (1977-1984, 1995-1996)
- Buick Skylark (1975-1979)
- Buick Commercial Chassis (1991-1996)
- Buick Roadmaster (1991-1996)
- Buick Riviera (1979-1985)
- Buick Regal (1975-1987)
- Buick LeSabre (1971-1986, 1988-1990)
- Buick Estate Wagon (1971-1983)
- Buick Electra (1971-1989)
- Buick Century (1975-1981)
- Buick Apollo (1975)
- Isuzu Hombre (1996-2000)
