CENTRIC 120.45090 Part Description
Manufacturer
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
- Painted hat and outer edge for corrosion resistance
- Symmetric vane; split-core castings for uniform heat distribution. Anti-corrosive paint protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life.
- Painted Hat and Outer Edge
- Optimal Surface Finish
- Optimal surface finish for consistent stopping feel from the first stop
- Advanced Metallurgy
- Advanced metallurgy for optimal heat transfer and structural strength
- OE Vane Design and Plate Thickness
- OE vane design and plate thickness for heat capacity and strength
- Low Initial Lateral Run-Out
- Low initial lateral run-out and disc thickness variation for smooth, vibration free stopping
- Precision Balance
- Precision balance for vibration free performance
CENTRIC 120.45090 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 128.000 |
| Weight [cntrc] Kgs | 6.040 |
| OEM Vane Count [cntrc] | 111 |
| Product Grade [cntrc] | Premium |
| Vane Style [cntrc] | Pillar |
| Misc Holes [cntrc] | 1 |
| Hat Id [cntrc] In | 5.039 |
| Weight [cntrc] Lbs | 13.300 |
| Discard Thickness | 20.000 MM |
| Discard Thickness | 0.787 IN |
| Nominal Thickness | 22.000 MM |
| Nominal Thickness | 0.866 IN |
| Hat Finish | Painted |
| Overall Height | 44.000 MM |
| Overall Height | 1.732 IN |
| Outside Diameter | 280.000 MM |
| Outside Diameter | 11.024 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.165 IN |
| Center Hole Diameter | 55.000 MM |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 13.100 MM |
| Stud/Lug Hole Diameter | 0.516 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 00889590178739 |
CENTRIC 120.45090 Cross References
| Brand | Part Number |
|---|---|
| N/A | 44827, 90080073, 6000615653, NA5F33251, NA5F33251A, 68338607AA |
| RAYBESTOS | 982092, 982092R |
| Raybestos Brakes | 982092, 982092R |
CENTRIC 120.45090 Fits Vehicles
- Fiat 124 Spider (2018-2020)
- Mazda MX-5 (2016-2022)
- Mazda MX-5 Miata (2016-2023)
