(888) 312-8812 Login SignupDELPHI FG2175 Fuel Pump Module Assembly
$58299
Limited availability at this price!
In Stock
Get it by Thursday, Dec 18
DELPHI FG2175 Part Description
DELPHI FG2175 Specifications
Product Attributes
| Fuel Level Sender Assembly Included | Yes |
| System Pressure | 80 psi |
| Item Grade | Standard Replacement |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seals, Instruction Sheet |
| Vapor Pressure Sensor | Yes |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 12 2H |
| Fuel Type | Gas |
| Regulator Included | Yes |
| Maximum Pressure | 84 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 2 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 250 82 |
| Resistance Ohms Full | 40 82 |
| Internal Or External Strainer | Internal |
| Pump Type | Electric |
| Average Current Draw | 14 68 |
| Average Flow Rating | 37 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Rectangle |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | Yes |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 46 PS |
| Wire Harness Included | No |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | Yes |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Country of Origin (Primary) | TH |
| Harmonized Tariff Code (HTS) | 9026204000 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604295311 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
DELPHI FG2175 Part Interchanges
| Brand | Part Number |
|---|---|
| Spectra Premium | SP6753M |
| ACDelco | M100221, M100236, MU2196, SK1500 |
| AutoZone | CFG2175 |
| General Motors | 13512935, 13513343, 13513344, 13535373, 13582497, 13535374 |
| Precision Fuel | A46072 |
| N/A | P77363M |
DELPHI FG2175 Fits Vehicles
- Chevrolet Suburban (2015-2020)
- GMC Yukon XL (2015-2020)
- Cadillac Escalade ESV (2015-2020)
