PARKER HANNIFIN part description

Air Brake Tubing - Nylon, 0.375" OD, 0.251" ID, Black, Reinforced, Polyamide (PA) Fiber Reinforcement (Sold Per Foot)



Product Specifications:
Color: Black
Product Type: Reinforced
Tube Material: Polyamide (PA) Fiber Reinforcement
Tube Inside Diameter: 6.4 mm, 0.251 Inch
Tube Outside Diameter: 9.5 mm, 0.375 Inch
Maximum Operating Pressure: 150 PSI, 10.3 Bar
Minimum Burst Pressure: 1400 PSI, 96.5 Bar
Maximum Operating Temperature: 200 °F, 93 °C
Minimum Operating Temperature: -40 °F, -40 °C
Minimum Bend Radius: 1-1/2 Inch, 38.1 mm
Size: -6
Cover Material: Polyamide (PA)
Application: Transportation, Air Brake
Compatible Fitting: NTA®, Air Brake, Prestomatic, SAE Cartridges, PTC
Specifications Met: D.O.T. 49 CFR 571.106, SAE J844
Media: Air

Product Description

Air Brake Tubing - Nylon, 0.375" OD, 0.251" ID, Black, Reinforced (Sold Per Foot)

Parker Hannifin® is a global leader in motion and control technologies. Included in the world's Fortune 250 companies, Park Hannifin's products are vital not only to automobiles but also to almost everything that moves or needs control. These include all forms of transportation, manufacturing and processing raw materials, as well as infrastructure development and construction. Established in 1918, the Parker Appliance Company's evolution into Parker Hannifin Corporation demonstrates a legacy of innovation and Parker's tradition of excellence. Parker Hannifin's product portfolio includes solenoid valves, hydraulic fittings, pressure relief valves, hydraulic pumps, polyurethane tubing, thermal and power management products, and other parts for climate control, hydraulics, filtration, fluid and gas handling, pneumatics, sealing and shielding, and many other applications.
