WABCO 9630010130 - Air Brake Quick Release Valve - Black, 123.28 psi, 2 x M8, With flange
$35099
MSRP: $614.23
Save: $263.24
Limited Availability
. Learn more
WABCO part description
Product Attributes
| Port Thread 1-2 | 0.28 in |
| Calculated Volume (dm³) | 0.2959 |
| Weight | 0.291 |
| Max. operating pressure | 123.28 psi |
| Max. operating pressure | 123.28 psi |
| Application | 971 002 |
| Temperature Range | -40°C to +80°C |
| Color | Knob - Black |
| Actuation | Black/Black |
| Type | Double Release valve |
| Port thread 22 | M16 x 1.5 |
| Port Thread 1-1 | M22 x1.5 |
| Port thread 2 | Ø 21.5 mm |
| Port thread 21 | M16 x 1.5 |
| Port threads | M22 x 1.5 |
| Size | 90.5 x 54.5 x 60 |
| Mounting | 2 x M8 - with flange |
| Distance Between Holes | 86 mm |
WABCO 9630010130 Cross Reference
We have 2 alternatives for the 9630010130 by WABCO:
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
