(888) 312-8812 Login SignupWABCO 4757145000 Air Brake Valve - Load Sensing Valve - Pneumatic, Static
Tap to view 3 more
MSRP: $1,613.03
$1,26599
Save $347.04
Limited Availability
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 4757145000 Part Description
WABCO 4757145000 Specifications
Product Attributes
| Regulating Range | 0.7 to 3.8 bar |
| Regulating Ratio | 1:8 |
| Max. operating pressure | 12.0 bar |
| Port thread 2 | 2x M16 x 1.5 |
| Port Thread 41 | M12 x 1.5 |
| Distance between bolts | 84x84 mm |
| Port thread 1 | M22 x 1.5 |
| Port Thread 42 | M12 x 1.5 |
| Port thread 4 | M22 x 1.5 |
| Break Point | 0.5 bar |
| Port Thread 43 | Test Connection |
| Port Thread 43 | Test Connection |
| Size | 308 x 195 x 144 |
| Weight | 4.2042 |
| Mounting | 4x M8 |
| Calculated Volume (dm³) | 8.6486 |
| Temperature Range | -40°C to +80°C |
| Type | Pneumatic |
| Type Of Operation | Static |
WABCO 4757145000 Cross References
We have 1 alternatives for the 4757145000 by WABCO:
WABCO 4757145000 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 4757145000 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
