MONROE part description

Product Description

Magnum Loaded Assembly Suspension Strut and Coil Spring Assembly

Features & Benefits

  • DESIGNED FOR TRUCKS -- Specifically designed for hardworking half-ton trucks that tow, haul, and plow
  • HELPS CARRY THE LOAD -- Variable rate coil spring delivers a comfortable ride and maintains ride height for everyday driving conditions or supporting the load
  • MAINTAINS VEHICLE CONTROL -- Acceleration Sensitive Damping (ASD) improves vehicle control over abrupt bumps, dips and potholes
  • BUILT TO LAST -- Bearing with PTFE coating protects the rod guide to reduce damage to the seal and chrome piston rod provides durability and long service life
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge helps maintain tire to road contact for improved ride and handling by reducing aeration and shock fade
  • REDUCES FRICTION -- Fluon-banded piston helps reduce friction between the piston and pressure tube to respond more quickly to changing road surfaces
  • RESPONDS TO CHANGING CONDITIONS -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
  • DUST BOOT/JOUNCE BUMPER -- Protective dust boot reduces dirt and moisture, while jounce bumper reduces severe suspension movement
  • BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee. Visit Monroe.com for details.

Product Attributes

Compressed Length 17.17 IN
Extended Length 21.64 in
Travel Length 4.47 in
Body Length 16.6 IN
Gas Charged Yes
Parts Pack(s) P01141
Mounting Hardware Included YES
Compressed Length 436.1 MM
Extended Length 549.7 MM
Travel Length 113.5 MM
Body Length 421.6 MM

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708809900
Harmonized Tariff Code (Schedule B) 8708801300
Harmonized Tariff Code (HTS) 8708801300
UPC 00048598223470
VMRS Code 016020001
UNSPSC 25172007

Part Interchanges

Fits Vehicles

  • Ford F-150 (2009-2013)
