*Representative image - actual part not displayed
Centric 125.34195 - Centric Premium High Carbon Alloy Brake Rotor
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric Premium High Carbon Alloy Brake Rotor
Features & Benefits
- Centric Premium Rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction; European style brake pad compounds. Added Molybdenum and Chromium to resist rotor cracking
Product Attributes
| Weight [cntrc] Kgs | 9.340 |
| Vane Style [cntrc] | Vented |
| Hat Id [cntrc] In | 6.063 |
| Weight [cntrc] Lbs | 20.550 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Misc Holes [cntrc] | 1 |
| OEM Vane Count [cntrc] | 36 |
| Product Grade [cntrc] | Premium |
| Hat Id [cntrc] Mm | 154.000 |
| Disc Mounting [cntrc] | Floating |
| Overall Height | 2.614 IN |
| Outside Diameter | 330.000 MM |
| Outside Diameter | 12.992 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.638 IN |
| Center Hole Diameter | 67.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 0.654 IN |
| Stud/Lug Hole Diameter | 16.600 MM |
| Overall Height | 66.400 MM |
| Hat Finish | Coated |
| Nominal Thickness | 24.100 MM |
| Nominal Thickness | 0.949 IN |
| Discard Thickness | 0.882 IN |
| Discard Thickness | 22.400 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590333763 |
Part Interchanges
Fits Vehicles
- BMW 230i (2022)
- BMW 330e xDrive (2021-2023)
- BMW 330i xDrive (2019-2023)
- BMW 330i GT xDrive (2019)
- BMW 430i xDrive (2021)
- BMW 430i (2021)
- Toyota GR Supra (2021-2023)
- BMW 330e (2020-2023)
- BMW Z4 (2019-2023)
- BMW X3 (2018-2023)
- BMW 330i (2019-2023)
- BMW X4 (2019-2023)
